The Water Fire Extinguisher (Stored Pressure) – 9 Litre is a dependable and eco-friendly firefighting solution designed to combat Class A fires involving common combustibles such as paper, wood, cloth, and plastics. This high-capacity extinguisher is ideal for environments that require extended discharge time and superior coverage.
Manufactured to meet the latest BIS standards (IS 15683:2006) and ISI marked, the unit features a corrosion-resistant design, high discharge efficiency, and is built for long-term performance in commercial, industrial, and institutional spaces. Whether it's an office block, factory floor, or warehouse, this extinguisher is a cost-effective and maintenance-friendly fire safety tool.
Key Features
Efficient Fire Suppression: Specifically designed for Class A fires involving ordinary combustibles.
CO₂ Expelling System: Equipped with a CO₂ gas cartridge conforming to IS:4947 for reliable pressure release and control.
Durable Valve System: Fitted with a high-quality brass chrome-plated valve for smooth operation and longevity.
Corrosion-Resistant Finish: Internal plastic lining and external pure polyester powder coating for enhanced durability.
Certified & Compliant: BIS approved (IS 15683:2006) and ISI marked for safety compliance.
Flexible EPDM Hose: Less prone to cracking, offering better maneuverability during use.
Tamper Evident: Features a tamper seal to indicate any unauthorized use or interference.
Anti-Corrosive Cylinder Treatment: Phosphate-treated cylinder ensures protection against rust and wear.
User-Friendly Activation: Large loop stainless steel pull pin and lever-lock mechanism for ease of handling.
Smart Labeling: Includes barcode labeling for efficient tracking and inventory management.
Low Maintenance: Simple to service, recharge, and maintain, reducing downtime and operational costs.
Technical Specifications
Parameter
Value
Model
KFWCRQ-9
Capacity
9 Litres
Fire Rating
3A
Design
Hose & Nozzle
Height (Approx.)
585 mm
Diameter (Approx.)
180 ±10 mm
Average Discharge Time
35 seconds
Average Range of Throw
6 meters
Average Discharge
95%
Operating Temperature
+5°C to +60°C
Service / Max. Service / Test Pressure
14 / 16 / 35 bar
Expelling Agent
CO₂ Gas
CO₂ Gas Cartridge
60 gm
Full Weight (Approx.)
14.8 kg
Empty Weight (Approx.)
5.8 kg
Shipping Weight (Approx.)
15.3 kg
Packing Standard
1 in 1 – 24.75" x 8" x 8"
Mounting Bracket
Wall Bracket
Approvals
BIS
