Key Features:
✔ High-Efficiency MAP 50% Powder – Effectively combats Class A, B, C, and electrical fires.
✔ Unique Gauge Testing System (UGTS) – Ensures reliable pressure monitoring for optimal safety.
✔ Premium Brass Chrome-Plated Valve – Enhances durability and corrosion resistance.
✔ Dual-Layer Coating – Internal epoxy-polyester and external pure polyester powder coating for superior protection.
✔ Industry-Leading Fire Ratings – Top-tier performance in its category (1A:21B rating).
✔ BIS Certified & ISI Marked – Fully compliant with IS 15683:2006 standards.
✔ Flexible EPDM Hose – Reinforced for longevity, minimizing crack risks.
✔ Tamper-Proof Seal – Detects unauthorized handling for added security.
✔ Anti-Corrosive Treatment – Phosphate-coated cylinder for extended lifespan.
✔ User-Friendly Design – Large stainless-steel pull pin, ergonomic lever lock, and barcode labeling for traceability.
✔ Low Maintenance – Easy to recharge, service, and maintain.
Technical Specifications - 2kg MAP 50% Dry Powder Fire Extinguisher
(Model: KFARQ-2-50%)
| Feature | Specification |
|---|
| Model Number | KFARQ-2-50% |
| Extinguishing Capacity | 2 kg of MAP 50% dry chemical powder |
| Design Type | Nozzle-operated system |
| Fire Rating | 2A:34B (Suitable for multiple fire types) |
| Physical Dimensions | Height: 380 mm
Diameter: 106±10 mm |
| Discharge Performance | Duration: 14 seconds
Range: 2 meters
Efficiency: 95% discharge rate |
| Temperature Range | Operational: -30°C to +60°C |
| Pressure Ratings | Service: 15 bar
Max Service: 18 bar
Test: 35 bar |
| Propellant Gas | Nitrogen (Ultra High Purity Grade) |
| Weight Specifications | Empty: 1.4 kg
Charged: 3.4 kg
Shipping: 3.6 kg |
| Packaging Details | Inner: 13.75"×4.75"×4.75"
Outer (4 units): 16.5"×10"×10" |
| Mounting Options | Universal vehicle/wall bracket included |
| Certifications | BIS Approved (IS 15683:2006) |
Key Performance Features
- Multi-Class Fire Protection: Effective on Class A, B, C and electrical fires
- Reliable Operation: Consistent 14-second discharge time with 2-meter reach
- Durable Construction: Designed to perform in extreme temperatures (-30°C to +60°C)
- Safety Compliant: Meets all BIS standards for portable fire extinguishers
- Space-Efficient Packaging: Optimized carton design for storage and shipping
